| Brand Name : | XQD |
| Model Number : | 3D-PXD |
| Price : | $0.07 - $0.10/pieces |
| Certification : | CE, RoHS, FCC |
| Delivery Time : | 10 work days |
| Supply Ability : | 50000PCS/Day |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Point Lights Led Waterproof Ip66 Leather Wire Light Christmas Decor LightsWaterproof full-color LED pixel screen
Mesh screens have significant advantages in the application of glass curtain walls. This display is mainly used outdoors, and its features include a permeable design, lightweight screen body and good heat dissipation performance, making it very suitable for installation on glass curtain walls and walls with low load.
The LED grille screen abandoned the sealed box and adopted the hollow-out design of the lamp strip, which not only increased the heat dissipation area, but also achieved a good display operation effect through natural ventilation and heat dissipation, and also avoided the additional use of air conditioning and other cooling equipment, saving costs. In addition, this screen body is lighter than the conventional screen body, and is more suitable for installation on glass curtain walls and other structures
| Basic product parameters | Product protection parameter | ||
| Product model | 3D-PXD-12V | Waterproof class | IP66 |
| Product size | Φ6mm*10mm | Shell flame retardant | V-0 |
| Application environment | outdoors | UV resistance grade | 4 |
| Product weight | About 0.75g | Salt spray test | Salt spray resistance |
| Shell material | PC | Impact resistance | IK10 |
| Maximum number of connections | 200PCS/ string | Electrical safety class | Type III |
| Center distance | 10cm±0.5mm | Safety certification | CE FCC RoHs |
| Average product life | 50000h | Operating temperature | -40℃-55℃ |
| Optional accessories | T-terminal/ crystal ball | Tensile strength | ≤4kg |
| Wire core | 3x0.11mm² | Instantaneous tensile strength | ≤8kg |
| Wire material | PVC | ||
| Colloidal material | UV light curing adhesive | ||
| Product optical parameters | Electrical parameters of the product | ||
| LED color | RGB | Operating voltage | DC12V |
| Luminous Angle | 360degree | Rated power | 0.1W |
| Color resolution | 3x8bit | Supporting system | |
| luminance | 1.6-2cd | ||
