    LED Secondary Packaging Point Light Waterproof IP68 For Street Bridge Building

    Ask Lasest Price
    Brand Name : XQD
    Model Number : 35 secondary packaging point light
    Certification : CE, RoHS, FCC
    Delivery Time : 10 work days
    Supply Ability : 50000PCS/Day
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    • Product Details
    • Company Profile

    LED Secondary Packaging Point Light Waterproof IP68 For Street Bridge Building

    35secondary Packaging Waterproof Street Bridge Building Lighting LED Point Light


    Product features:

    Billboard lighting
    Text, pattern and logo: LED point light sources can provide high-brightness lighting effects for the text, pattern and logo of the billboard, and compared with traditional fluorescent lamps and neon lights, LED point light sources have higher energy efficiency, longer service life and lower maintenance costs.
    Outline the building
    Buildings, houses, Bridges: Point light sources can be used to outline the outline of the building, especially in the roof lattice screen, building facade wall lighting and other applications, can enhance the visual impact of the building.

    Building night lighting
    Full-color DMX512 point light source: such as the 30mm full-color DMX512 point light source used in the night lighting project of the building of Wuxi Nanyang Commercial Bank, through the secondary packaging injection molding integrated molding technology, to achieve a waterproof level IP68, can be used underwater. In addition, the UV resistance level of the lamp body material reaches more than 4, will not change color significantly in 5 years, flame retardant grade V-0, and self-extinguishing from fire to ensure safety and durability.


    Applications:
    Widely used in billboards, highways, railway tunnels, bridges, squares, stadiums, trees, parking lots,

    building walls, hotel, meeting room, offices , hospital , schools , factories , commercial lighting ,

    shopping malls, supermarkets, kitchen, display, backlight and so on.


    Basic product parametersProduct protection parameter
    Product modelXQD-DZ103-ⅠWaterproof gradeIP66
    Product sizeΦ29.8mm*10.5mmShell flame retardantV-0
    Application environmentIndoor and outdoorUV resistance grade4
    Product weightAbout15gSalt spray testSalt spray resistance
    Shell materialPVCImpact resistanceIK10
    Maximum number of connections100PCS/stringElectrical safety classⅢ class
    Average product life50,000 hoursOperating temperature-40℃-55℃
    Optional accessoriesAluminum groove, steel wire buckle
    Wire core2x0.75mm²+3x0.35mm²
    Wire materialPVC
    PCB materialFR-4 Fiberglass board
    Product optical parametersElectrical parameters of the product
    Luminous Angle120°Rated power0.72W
    Color resolution3*16bitSupporting system
    Lamp beadSMD5050*3LEDControl systemDMX512
    Pixel point luminous flux21.8lmPower supply systemDC12V Constant voltage
    luminance7.4cd
